GOWE DAC PCM1792 chip 8GB Portable audio music player

GOWE DAC PCM1792 chip 8GB Portable audio music player

• Features: 1.Replaceable DAC board and amp card, DAC software selectable; 2.Support to adjust digital filter response sharp / slow; 3.Support digital volume control; 4.Pop-noise Free, completely eliminate the POP sound; 5.Support USB DAC function; 6.Support WAV, APE, FLAC, MP3 format playback;
• 7.2.0V RMS Line out level output; 8.AD8397 high-power amp card; 9.Built-in 8G flash memory, support TF card expansion, 32G available. 10.Multi-language support for Simplified Chinese, Traditional Chinese, English, Russian, Japanese; 11.Rockbox compatible software (another set of dual-boot software);
• Design features: 1.The new DAC uses BB incumbent top-DAC PCM1792, differential treatment, to effectively improve the signal to noise ratio and improve the details of music to restore the slightest will now. 2.Precision reference by the way high-speed op amps expansion flow regulated power supply for the DAC, and further improve the sound quality. 3.Use quality SMD Film Chip Capacitors, reducing the loss of quality.
• 4.POP sound elimination circuit at the cost of using the industry's smallest relays, eliminating the very thorough. 5.Master, amp and DAC with 4 shelves large area paved, greatly reducing signal interference, while ensuring power supply part of the low-resistance. 6.Master use shielded box Shielded master complete, optimized alignment, digital simulation point grounding to eliminate the digital part of the noise. 7.All units separate power amp section uses Ti ultra low noise regulator.
• 8.The new amp board, optimize the layout, use the classic AD797 op amp. Technical Specifications: Screen:2.36 inch 320*240 TFT; Inner memory:8G; Support memory card:TF/SDHC Card ( up to32G ); Line output:3.5mm ; earphone output:3.5mm ; language optionChinese :English, Japanese; Playe time:8-9 hours; Charging time:2 hours; power adapter:9V; Innfer battery:1150mAh 8.4V lithium battery;
